Khoom Taw Qhia
1. Cov tam sim no loj: Qhov kev tiv thaiv lub voj voog tiv thaiv no tuaj yeem paub txog cov khoom siv hluav taws xob ruaj khov tam sim no los ntawm qhov chaw tam sim no, uas kov yeej qhov kev ua tsis zoo ntawm tam sim no ntawm impulse hom fais fab, tuaj yeem ua tau zoo los ntawm oxide zaj duab xis ntawm kev sib cuag, tau txais cov txiaj ntsig kev xeem raug.
2. Kev ruaj ntseg siab. nyob rau hauv muaj zog cuam tshuam, tus lej kawg ntawm cov zaub tuaj yeem ruaj khov nyob rau hauv ± 1 lo lus ntau, kev nyeem ntawv ruaj khov thiab zoo re-producibility.
3. Lub neej ntev kev pab cuam: siv high precision tsis kam mus tshem tawm cov nyhuv ntawm ambient kub
4. Yooj yim rau siv: me me hauv ntim, lub teeb hauv qhov hnyav.
5. Kev xaiv los tsim hauv lub tshuab luam ntawv lossis tsis muaj lub tshuab luam ntawv
Khoom Parameter
|
Qauv |
JHH600A |
|
Kev ntsuas ntau |
1~10mΩ |
|
Kev daws teeb meem |
1μΩ |
|
Test tam sim no (customized) |
DC 600A |
|
Qhov tseeb |
0.50% |
|
Lub sijhawm ua haujlwm tsis tu ncua |
100A:600S,200A:60S,400A:10S,600A:10S |
|
Zaub |
Peb thiab ib nrab digital LED zaub |
|
Fais fab mov |
AC220V ± 10% 50Hz |
|
Kev pabcuam |
Kub -10℃~ 40 degree, av noo: Tsawg dua los yog sib npaug rau 80% RH |
|
Dimension |
350 × 350 × 510 hli |
|
Qhov hnyav |
30 Kg |
